Motherboard STH-1
Thin Mini-ITX 170×170mm Board For AMD FP11 Strix Halo128GB LPDDR5X (8×16GB) On-Board Memory For Local AI WorkloadsDual M.2 PCIe 4.0×4 + Dual HDMI 2.1 + Expandable USB Headers
Variant
Power Plug Type
$1,595.00
1
Shipping address and contact details are collected on Stripe's secure checkout page.
Free shipping included — no hidden fees
Specifications
- Form Factor
- Thin Mini-ITX · 170×170mm
- CPU Platform
- AMD FP11 (Strix Halo family)
- Memory
- LPDDR5X 315-ball · Up to 128GB (soldered)
- Storage
- 2× M.2 2280 PCIe 4.0×4 + 1× M.2 2230 (Wi-Fi)
- Video Out
- 2× HDMI 2.1 + 1× DP/VGA/COM (optional)
- Rear USB
- 2× USB 3.2 Gen2 + 2× USB 2.0
- Header USB
- 2× USB 3.2 Gen1 + 5× USB 2.0 (via headers)
- Networking
- 1× Gigabit LAN (RJ45)
- Power Input
- 19V DC-IN
- OS Support
- Windows 10 / Windows 11 / Linux
